Width | 149cm (59") |
Height | 101cm (40") |
Depth | 161cm (5'3") |
Weight | 316kg (695lbs) |
|
Piano silencing mechanism | Yes (Motor-driven hammer shank stopper) |
|
Piano Sound | CFX Binaural Sampling / CFX Stereo Sampling |
Polyphony (max.) | 256 |
Number of voices (playing) | 16 (Piano, Electric Piano 1-3, Harpsichord 1 & 2, Vibraphone, Celesta, Pipe Organ 1-4, Jazz Organ, Strings, Choir, Synth Pad) |
Number of voices (playback) | 480 XG Voices & 12 Drum Kits |
Compatibility XG | Yes |
Compatibility GM | Yes |
|
Number of built-in songs | 500 (Pop, Jazz, Classical, Smart Key etc . 380 piano solo son gs (PianoSoft Solo), 72 songs with instr umental accompanimen ts (PianoSoft Plus), and 48 songs with a udio backing (PianoS oft Audio)) |
Compatible data format | SMF (Standard MIDI File, Format 0 & 1), MP3, WAV |
Compatible song format | PianoSoft, PianoSoft Plus, PianoSoft Audio, SmartKey |
|
Recording functions | Yes |
Tuning | 414.8 HZ- 466.8 Hz (Tunable in ±0.2 Hz) |
|
Headphones | Mini stereo jack (x2) |
MIDI | IN/OUT |
OUTPUT | Yes |
DIGITAL OUT | Yes |
USB TO DEVICE | x3 |
USB TO HOST | Yes |
OMNI (SYNC) | IN/OUT |
USB Flash memory (Optional) | Yes |
|
Power requirements | AC100 V - 240 V, 50/60 Hz |
|
Included accessories | Monitor Speaker x2, Speaker Hanger x2, Stereo Headphone, Operation Manual, Built-in Song List, Music Book 50 Greats for the Piano, USB Wireless LAN Adaptor (UD-WL01) |
|
Key sensors | Non-contact Optical Fiber Grayscale Shutter Sensing System for 88 keys (Sensors for the key position, keying velocity, and key releasing velocity) |
Hammer sensors | Non-contact Optical Fiber/shutter Sensing System |
Pedal sensors | Damper & Shift pedal: Non-contact Optical Position-sensing System, Sostenuto pedal: ON/OFF Detection Sensing System |
Key drive | DSP Servo Drive System (Servo-controlled solenoids, Key sensor feedback) |
Pedal drive | DSP Servo Drive System (Servo-controlled solenoids) |
