Size/Weight | | |
Dimensions | Width | 1,450 mm [57-1/16"] Polished finish: 1,455 mm [57-5/16"] |
| Height | 927 mm [36-1/2"] (music rest raised: 1,083 mm [42-5/8"]) Polished finish: 930 mm [36-5/8"] (with music rest raised: 1,084 mm [42-11/16"]) |
| Depth | 460 mm [18-1/8"] Poliwith shed finish: 460 mm [18-1/8"] |
Weight | Weight | 57 kg [125 lb, 11 oz] Polished finish: 60 kg [132 lb, 4 oz] |
Dimensions of Packing Box | W x H x D | 1,571 mm x 639 mm x 569 mm [61-7/8" x 25-3/16" x 22-3/8"] |
Control Interface | | |
Keyboard | Number of Keys | 88 |
| Type | GrandTouch-S™ keyboard: synthetic ebony and ivory key tops, escapement |
| Touch Sensitivity | Hard2, Hard1, Medium, Soft1, Soft2, Fixed |
| 88-key Linear Graded Hammers | |
Pedal | Number of Pedals | 3: Damper (with half-pedal function), Sostenuto, Soft |
| GrandTouch Pedals | Yes |
| Assignable Functions | Sustain (Switch), Sustain (Continuous), Sostenuto, Soft, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause |
Display | Type | Full Dots LCD |
| Language | English, Japanese |
| Type | Buttons |
| Language | English |
Cabinet | | |
Key Cover Style | Sliding | |
Music Rest | Yes | |
Music Braces | Yes | |
Voices | | |
Tone generator | Piano Sound | Yamaha CFX, Bösendorfer Imperial |
| Binaural Sampling | Yes (“CFX Grand” and “Bösendorfer” only) |
| Virtual Resonance Modeling (VRM) | Yes |
| Grand Expression Modeling | Yes |
Polyphony | Number of Polyphony (Max.) | 256 |
Preset | Number of Voices | 38 |
Effects | | |
Types | Reverb | 7 types |
| Chorus | 3 types |
| Brilliance | 7 types + User |
| Insertion effect | 12 types |
| Intelligent Acoustic Control (IAC) | Yes |
| Stereophonic Optimizer | Yes |
Functions | Dual/Layers | Yes |
| Split | Yes |
| Duo | Yes |
Songs | | |
Preset | Number of Preset Songs | 23 Voice Demo + 50 Classics + 303 Lesson Songs |
| Number of Songs | 250 |
| Number of Tracks | 16 |
| Data Capacity | Approx. 500 KB/Song (approx. 22,000 notes) |
Audio Recording (USB flash drive) | Recording Time (max.) | 80 minutes/Song |
| Recording Time (max.) | SMF (Format 0, Format 1), WAV (44.1 kHz, 16-bit, stereo) |
| Recording | SMF (Format 0), WAV (44.1 kHz, 16-bit, stereo) |
Functions | | |
Piano Room | | Yes |
Rhythm | Number of Rhythms | 20 |
| Metronome | Yes |
| Tempo Range | 5 – 500 |
| Transpose | −12 – 0 – +12 |
| Tuning | 414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments) |
| Scale Type | 7 types |
| USB Audio Interface | 44.1 kHz, 24 bit, stereo |
| | Audio, MIDI (varies by area) |
Bluetooth | | |
Storage and Connectivity | | |
Storage | Internal Memory | Total maximum size approx. 1.4 MB |
| External Drives | USB flash drive |
Connectivity | Headphones | Standard stereo phone jack (× 2) |
| AUX IN | Stereo mini jack |
| AUX OUT | Standard phone jack (L/L+R, R) |
| USB TO DEVICE | Type A |
| USB TO HOST | Type B |
| DC IN | 16 V |
Amplifiers and Speakers | | |
Amplifiers | | 30 W × 2 |
Speakers | | 16 cm with diffuser × 2 |
Power Supply | | |
Power Consumption | | 18 W (When using PA-300C AC adaptor) |
Auto Power Off | | Yes |
Accessories | | |
Included Accessories | | Owner’s Manual, “50 Classical Music Masterpieces” Music Book, Online Member Product Registration, Bench*, Power cord*/AC adaptor* (PA-300C) *Varies by area |
